Facilities List
Turning Milling Drilling Grinding Miscellaneous Auxiliary Software
TURNING EQUIPMENT:
Haas SL-40L CNC Turning Center
40" Swing, 80" Centers, 7" Thru Hole, w/ Chip Conveyer |
| |
Mazak Slantmaster CNC Turning Center
26" Swing, 80" Centers, 4-1/2" Thru Hole, w/ Chip Conveyer |
Mori Seiki SL-3B CNC Turning Center
9" Swing, 2-3/8" Thru Hole, 8 Tool Turret, w/ Chip Conveyer |
Hitachi Seiki 4NE-600 CNC Turning Center
22-3/4" Swing, 24" Centers, 2-3/4" Thru Hole, w/ Chip Conveyer |
| Warner & Swasey No. 3 Electro Cycle Turret Lathe 15" Swing |
Warner & Swasey No. 3A Saddle Type Turret Lathe
23-1/2" Swing, 6-1/4” Thru Hole, w/ Newall Digital Readout |
J&L 7A-3-1/2 Turret Lathe
20" Swing, 4-1/2" Thru Hole, 40" Centers, w/ Newall Digital Readout |
| Atlas 10" Quick Change Bench Lathe |
Top of Page
MILLING EQUIPMENT:
Mitsubishi M-H60D Horizontal Machining Center
w/ 2 24” Pallets, 1/10˚ Indexing, 40 Tools, 4000 RPM Spindle |
| |
Mitsui Seiki HR3C Horizontal Machining Center
w/ 2 16” Pallets, 1˚ Indexing, 60 Tools, 6000 RPM Spindle |
| |
Two Haas CNC Tool Room Mills
10-1/2” x 47-3/4” Table, 30” x 12” x 16” XYZ Travel, with 10 Station Tool Changer |
Siber Hegner RB-1 Variable Speed
Rigid Bed Mill, w/ 3 Axis Digital Readout, 9" x 42" Table |
Bridgeport J-Head Series 1 Mill
w/ Power Feed, w/ 2 Axis Digital Readout, 9" x 48" Table |
Brown & Sharpe No. 2 Plain Horizontal Mill
10" x 60" Table, w/ Universal Vertical Head |
Top of Page
DRILLING EQUIPMENT:
| 4 Foot Carlton Radial Drill 11" Column, #4MT |
Drillmation Model 4960 Heavy Duty Gun Drill
48" Stroke, 1-1/2" Diameter Capacity |
Drillmation Model M-18 Knee Type Gun Drill
16” Stroke, 3/4” Diameter Capacity, 2 Axis Digital Readout |
| Cleereman 5 HP Geared Head Drilling and Tapping Machine |
| Delta Drill Press 17" Swing |
| Walker-Turner Drill Press 9" Swing |
| Delta Drill Press 7" Swing |
Top of Page
GRINDING EQUIPMENT:
Fortuna FM4 CNC Cylindrical Grinder
10” Swing, 25” Centers |
| |
CV-616 Sunnen Vertical Honing Machine
Length Range up to 18”, Diameters up to 8” |
Sunnen Honing Machine, Model MBC-1805
Diameters from .060” – 6.500” Length Range up to 16.00” (depending on bore diameter), power stroking automatic cycles |
| |
Ramco LF-800G Cylindrical Grinder
10" x 32" Capacity, w/ Internal Grinding Unit, w/ .0001” Readout |
| Reid 6" x 18" HYD-DF Hydraulic Surface Grinder |
| Hammond 12" 2HP Pedestal Grinder |
| Mohawk Model 100, 3" Capacity Drill Grinder |
| Myford Cylindrical Grinder w/ .00002" Resolution Readout |
| Gorton Model 375 Pin Grinder |
| Medina Model B End Grinder |
Top of Page
MISCELLANEOUS EQUIPMENT:
| Press Master 150 Ton Hydraulic Shop Press |
| Grob 24" Vertical Band Saw |
| Oliver Die Filer |
| Greenerd No. 3-1/2 Arbor Press 5-Ton Capacity |
| |
Peerless Model 1400 Fully Automatic Production Band Saw |
| Cammann Metal Disintegrator |
ELTEE Pulsitron TR30/EP30 Ram Type EDM
30 Amp, 12” x 20” Tank, .0001” Digital Readout |
| Two Abrasive Blast Cabinets |
Top of Page
AUXILIARY EQUIPMENT:
Brown & Sharpe Reflex
CMM
.0000025" Resolution, 18" x 20" x 16" Measuring Range |
| Gorbel 1-Ton Bridge Crane 30’ x 100’ |
Mitutoyo DP-3DX Microprocessor, and Complete SPC/SQC Gaging System
Sunnen Bore Gages, .0001” Resolution, Range .7400” – 6.1250” Diameter |
| 36" x 48" Starrett Surface Plate |
| 10" Dial Height Gage |
| 18” Dial Height Gage |
| Positech Model TPA-5 Manipulator 200-lb. Capacity |
| Hyster 6000-lb. Lift Truck |
| Yale 3000-lb. Stand-Up Fork Lift |
| |
SECO 6" X 12" X 18",
2400˚ F Heat Treat Furnace and
Lindberg "Cyclone" 18" x
12" x 18", 1250˚ F Draw Furnace |
Lucifer 10" x 10" x 20" HDL-8012-C 2300˚ F Dual Chamber
Electric
Heat Treat Furnace |
| Sentry 6” x 6” x 14” 3000˚ F Electric Heat Treat Furnace |
| Bayco 24” x 24” x 40” BB-12 Burnoff Furnace |
| 15-HP Quincy Air Compressor with Refrigerated Dryer |
| |
Wilson Rockwell Hardness
Tester |
| Assorted Inspection Equipment |
Top of Page
SOFTWARE COMPATIBILITY:
| Bobcad Version 22.0 Cam Package |
| Autocad LT 2006 CAD Package |
|
